60W Welder Jewelry Laser Welding Machine Handicraft Laser Welding Medical Denture Laser Spot Welding Machine Factory Direct Sales

Basic Info

After-sales Service	Yes
Warranty	One Year Warranty
Application	Manufacturing Industry, Jewelry Industry
Technical Class	Pulse Laser
Control	Manual
Power Density	Heat Conduct Welding
Laser Classification	Optical Fiber Laser
Type	Laser Source Welding
Transport Package	Wooden Case Parking
Specification	550x300x430mm
Trademark	LEADINGLASER
Origin	Shenzhen/China
HS Code	8515809090
Production Capacity	300 Sets/Year

Product Description

Jewelry laser welder is mainly used in perforating and spot welding of white gold, platinum, carbon steel. The spot welding process is thermal conduction, i.e. the laser radiation heats the surface of work piece, and the surface heat diffuses to the interior through thermal conduction and melts the work piece by controlling the pulse width, frequency of laser pulse to form specific molten pool.

Features:

1. No need to change xenon lamp.
2. No need to fill water.
3. No need to adjust the spot light path.
4. Mini spot laser welder, work when plugged in, 24 hours of uninterrupted work, and the weight is only 20kg.
5. The core components use 60W Fiber laser source.
6. Compact design, saving space in the workshop or studio, and convenient transportation.
7. The microscope adopts the best brand in China, which is 1.5 times the cost of other ordinary microscopes.
8. Color touch screen, friendly human-computer interface.

Application:
Suitable for laser welding of gold and silver jewelry, laser welding of stainless steel jewelry, manual laser welding of fine metal parts.Technology parameter:

Input voltage	AC220V±10% 50Hz
Laser frequency	1.0-50Hz
Pulse Width	0.5-50ms
Spot adjustment range	0.3-1.5mm
Maximum laser power	60W
Machine power consumption	300W
Aiming and positioning	Microscope
Ambient temperature	10-45ºC
Cooling method	Air cooling
Laser wavelength	1064nm
Display touch screen size	7 inch
Overall size	550x300x430mm
Net weight	20Kg

Welding effect



We are manufacturer of laser welding machine with 10 years of production experience.We offer complete machine solution,also provide laser source,CNC controller ,laserhead, water chiller,servo,custom made machine table,training and service,etc. one-stop solution!

If you need other products,Contact us freely!
